7.5 ft./min cutting speed for excellent work progress.
Optimum ergonomics, including a motor housing that is up to 20% slimmer thanks to an extremely narrow drive head.
Cutting direction setting can be changed in 45° increments up to 360° using tool-free pivoting cutting head.
QuickIN rapid change system.
Rotating punch for up to 30% longer service life.
Low operating costs due to long tool life of punch and die.
Motor with outstanding performance and stability.
Chip protection mesh on vent slots.
16 ft. cable.
Brief overlapping area up to 12 gauge.
Stainless steel up to 25 gauge.

Interested in this item or want more information?
Monday—Friday: 6:30am till 4:30pm EST
Saturday—Sunday: Closed
Phone: 1-800-796-4716
Email: sales@tatool.net

Can't find what you want? Give us a call and we can help you find it.

Details

Power consumption: 350 Watts

Power output: 210 Watts

Strokes: 1,800 rpm

Cutting speed: 7.5 ft/min

Cable with plug: 16 ft

Weight according to EPTA: 4.0 lbs

Steel 56,000 lbf/in²: 18 gauge

Steel 84,000 lbf/in²: 21 gauge

Steel 112,000 lbf/in²: 23 gauge

Non-ferrous metals up to 35,000 lbf/in²: 14 gauge

Cutting width: ³/16 in

Immersion Ø with die: ¾ in

Radius of smallest curve (inside/outside): ?/16 / ¹³/16 in

Price Includes:

1 punch (6 36 02 050 00 0)

1 die for trapezoidal sheet metal (3 01 09 170 00 1)

Additional Information

Manufacturer: Fein Tools
