Cutters available in 1', 2' & 3' depths.
Heavy duty magnetic holding power.
Optional chuck and adaptor for twist drills up to 5/8' diameter to be used.
Integrated coolant system.
Two Speed Mechanical Gearbox for optimum RPM spped on different size cutters.
High quality construction.
Switches are protected with bar guards.
Spoke handles can be mounted on right or left side.
Front handle provides ease of positioning for the machine and assists in carrying the machine.

Interested in this item or want more information?
Monday—Friday: 6:30am till 4:30pm EST
Saturday—Sunday: Closed
Phone: 1-800-796-4716
Email: sales@tatool.net

Can't find what you want? Give us a call and we can help you find it.

Details

Technical Specifications:

Motor 120v ~ 60Hz - 1800W
Amps - 15A
Horse Power - 2.4HP
Speed (No Load) - 380 RPM / 500 RPM
Maximum Cutter Diameter - 2-3/8'
Maximum Cutting Depth - 3'
Recommended Maximum Dity Cycle - 30 mins
Sound Pressure Level (Under Load) 104dB(A)

Magenetic Holding Power - 4400 lbs

Cutter Shank Diameter - 3/4' Weldon Shank

Stroke Length - 4-7/8'

Tool Weight - 50 lbs

Rack Raised (H x W x L) - 24-1/8' x 9' x 11-1/2'

Rack Lowered (H x W x L) - 19-7/8' x 9' x 11-1/2'

Magnetic Dimensions (H x W x L) - 3-2/3' x 2-1/2' x 7-5/6'

Supplied with:
Coolant Tank, Quick Release Coolant Pipe, Permanent Safety Guard, Hex Key 2.5mm, Wrench 8mm, 4 Handles, 2 Butterfly Screws, 2 Spring Washers, Safety Chain, Carrying Case, Safety Goggles, Ear Plugs, Manual.

Additional Information

Manufacturer: Evolution Power Tools
