Cuts through mild steel with ease, producing no burrs and virtually no sparks
Long blade life averages 1000 cuts of 2' x 2' in mild steel (1/8' wall thickness).
Faster and cleaner cuts than an abrasive wheel.
Work clamp and V-Block provide strong support for work piece including pipe.
Also cuts stainless steel, aluminum, and wood with the correct specialty blade attached.
Built in Collection bin for catching debris.
Instantly workable finish
High quality construction.

Interested in this item or want more information?
Monday—Friday: 6:30am till 4:30pm EST
Saturday—Sunday: Closed
Phone: 1-800-796-4716
Email: sales@tatool.net

Can't find what you want? Give us a call and we can help you find it.

Details

Technical Specifications:

Motor 120v ~ 60Hz - 2200W
Amps - 15A
Horse Power - 3.0HP
Speed (No Load) - 1450 RPM
Recommended Maximum Duty Cycle - 30 mins
Sound Pressure Level (Under Load) - 112.4 dB(A)
Optimum Thickness of Cut (Mild Steel Plate) - 1/2'
Max Cut Reach 90° (1/4' Wall - Square) - 4 3/4' x 4 3/4'
Max Cut Reach 90° (1/4' Wall - Rectangle) - 4' x 7'
Max Cut Reach 90° (1/4' Wall - Round) - 5 1/8'
Max Cut Reach 45° (1/4' Wall - Square) - 3 1/2' x 3 1/2'
Max Cut Reach 45° (1/4' Wall - Rectangle) - 3' x 4 7/16'
Max Cut Reach 45° (1/4' Wall - Round) - 4 1/8'
Tool Weight - 50 lbs
Tool Dimensions (H x W x L) - 23 1/2' x 13 1/4' x 23 3/4'

Blade Specifications:

Diameter - 14'
Bore - 1'
Kerf (Thickness) - .094' (2.4')
Number of Teeth - 66

Supplied with:
14' steel Cutting Blade, V-Block, Safety Guard, Collection Bin, Spare Carbon Brush Set, Hex Wrench, Safety Goggles, Ear Plugs, Manual.

Additional Information

Manufacturer: Evolution Power Tools
