2,000 Volt rated
90°C wet/dry rated for continuous exposure
Approved for CT use (1/0 & larger)
Excellent impact resistance, high level of abrasion resistance
Fully annealed, highly flexible, stranded, tin coated copper conductor
Highly resistant to oils, alkalais, and acids
NEC suitable as flexible wiring for installation in open air, trays (1/0) or conduit
Suitable for -40°C applications
UL sunlight resistant
8 AWG through 535 MCM, fully annealed tinned copper in accordance with AAR-598 and ASTM B33

Interested in this item or want more information?
Monday—Friday: 6:30am till 4:30pm EST
Saturday—Sunday: Closed
Phone: 1-800-796-4716
Email: sales@tatool.net

Can't find what you want? Give us a call and we can help you find it.

Details

APPLICATIONS :-

Cranes and hoists
Diesel-Electric locomotive traction motor leads
Electrical generation and other utility facilities
Heavy electric earth-moving equipment
Mining and other industrial equipment
Offshore oil drilling platforms & Onshore drilling rigs
Rail and transit cars
Shipyard welding and other high draw machines

INDUSTRY APPROVALS :-

UL Listed under UL Standard 44, Type RHH/RHW-2 (600 volts or 2,000 volts)
RoHS and REACH Compliant
MSHA-Rated Flame Retardant
ICEA S-95-685/ NEMA WC70
CSA RW90 @ 1,000 Volt
FT4 Available upon request

Part Number	AWG, kcmil	No. Cond.	Stranding	Insulation Wall, Nom.		Jacket Wall, Nom.		O.D., Nom.		Net Weight		Amps*	Nom. DCR ?/1M'
				Inches	mm	Inches	mm	Inches	mm	lb./kft.	kg/km
167014	8	1	37/24	0.055	1.40	0.030	0.76	0.349	8.86	94	140	80	0.679

Additional Information

Manufacturer: Coleman Cable - CCI
