Details

Pure50+    Epoxy Injection Adhesive Anchoring System

Product Description :
The Pure50+ is a two-component adhesive anchoring system. The system includes injectionadhesive in plastic cartridges, mixing nozzles, dispensing tools and hole cleaning equipment.The Pure50+ is designed for bonding threaded rod and reinforcing bar hardware into drilledholes in solid concrete base materials.

General Applications and Uses :

Bonding threaded rod and reinforcing bar into hardened concrete

Evaluated for installation and use in dry and wet holes

Can be installed in a wide range of base material temperatures

Features and Benefits :
+ Designed for use with threaded rod and reinforcing bar hardware elements
+ Evaluated and recognized for freeze/thaw performance
+ Cartridge design allows for multiple uses using extra mixing nozzles
+ Mixing nozzles proportion adhesive and provide simple delivery method into drilled holes
+ Evaluated and recognized for long term and short term loading (see performance tables for applicable temperature ranges)

Approvals and Listings :
Conforms to requirements of ASTM C 881, Types I, II, IV and V, Grade 3, Classes B & C (also meets Type III except for elongation)Department of Transportation listings – see www.powers.com or contact transportation agencyTested in accordance with AC308 for use in structural concreteEvaluated and qualiied by an accredited independent testing laboratory for recognition in concrete

Guide Specifications :
CSI Divisions: 03151-Concrete Anchoring.Adhesive anchoring system shall be Pure50+ as supplied by Powers Fasteners, Inc., Brewster, NY. Anchors shall be installed in accordance with published instructions and requirements of theAuthority Having Jurisdiction.

View Product Specification

View Submittals
English


View Instruction Card
English

Additional Information

Manufacturer: Anchors Powers DeWalt
